GE MiCOM P143 Agile User Manual

P14xEd1
Appendix A - Ordering Options
Variants Order No.
Feeder Management P141 **
Design Suffix
CPU3 with extended memory, dual characteristic opto inputs, IEC61850, InterMICOM P
CPU3, dual characteristic opto inputs, IEC61850, InterMICOM J
Phase 2 CPU, UCA2 G
Second comms card, IEC60870 private codes, P144, improved power supply C
Expansion I/o and IDMT characteristic enhancements B
Original Release - Phase 1 A
V
x Auxiliary Rating
24-54 Vdc 7
48-125 Vdc (40-100 Vac) 8
110-250 Vdc (100-240 Vac) 9
In/Vn Rating
In = 1/5A, Vn = 100 - 120Vac 1
In = 1/5A, Vn = 380 - 480Vac (Min 196Vac Max 560Vac) 2
Hardware Options Protocol Compatibility Design Suffix Compatibility
Standard - None 1, 2, 3 & 4 All 1
IRIG-B - (Modulated) Only 1, 2, 3 & 4 All 2
3 All
1, 2 & 4 J/P
3 All
1, 2 & 4 J/P
Ethernet (10 Mbps) 5 G/J/P * 5
Ethernet (100 Mbps) 5, 6, 7 & 8 G/J/P * 6
Courier Rear Port 1, 2, 3 & 4 C, G, J or P 7
IRIG-B (Modulated) & Courier Rear Port 1, 2, 3 & 4 C, G, J or P 8
Ethernet (100Mbit/s) plus IRIG-B (Modulated) 6, 7 & 8 J/P * A
Ethernet (100Mbit/s) plus IRIG-B (Un-modulated) 6, 7 & 8 J/P * B
IRIG-B (Un-modulated) 1, 2, 3 & 4 J/P C
InterMiCOM + Courier Rear Port 1, 2, 3 & 4 J/P E
InterMiCOM + Courier Rear Port + IRIG-B modulated 1, 2, 3 & 4 J/P F
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** M
Redundant Ethernet PRP/HS
R
, 2 fibre ports + Modulated IRIG-B
6, 7 & 8 J/P *** N
Redundant Ethernet PRP/HS
R
, 2 fibre ports + Unmodulated IRIG-B
6, 7 & 8 J/P *** P
Product Specific Option
40TE Case, 8 inputs & 7 relay outputs A
40TE Case, 8 inputs & 8 relay outputs N
* Only Available with software versions 44 and later
Protocol / Communications Options Hardware Compatibility Design Suffix Compatibility
K-Bus/Courier
1 & 2 All
7 or 8 C, G, J or P
C, E & F J/P
3 & 4 J/P
1 & 2 All
7or 8 C, G, J or P
C, E & F J/P
3 & 4 J/P
1, 2, 3 & 4 All
7or 8 C, G, J or P
C, E & F J/P
1 & 2 All
7 or 8 C, G, J or P
C, E & F J/P
3 & 4 J/P
UCA2 5 & 6 G or J * 5
6, A, B, G, H , J, K, L, M, N, P J/P 6
6, A, B, G, H , J, K, L, M, N, P J/P
7
6, A, B, G, H , J, K, L, M, N, P J/P
8
* NB: UCA2 option is not available with software versions 32, and later (Design Suffix J)
Mounting Option
Flush Panel Mounting, with Harsh Environment Coating M
Flush Panel Mounting, with harsh environment coating P
Multilingual Language Option Design Suffix Compatibility
English, French, German, Spanish All 0
English, French, German, Russian G, J or P 5
English, Italian, Polish and Portuguese (Software '50' and later)
J/P 7
J/P
C
Software Issue **
Customisation
Default 0
Customer specific A
DNP3.0 4
IEC 61850 over Ethernet and Courier via rear K-Bus/RS485
IEC61850 over ethernet with CS103 rear port RS485 protocol
DNP3 over Ethernet with Courier rear port K-Bus/RS485 protocol
Chinese, English or French via HMI, with English or French only via Communications port
*** Only available with software version 46 and later
1
Modbus 2
IEC 60870-5-103 (VDEW) 3
** Only available with software versions 43 and later
Fibre Optic Port (ST) for SCADA Protocols (Courier,Modbus,IEC60870-5-103 or DNP3) 3
Fibre Optic Port (ST) for SCADA Protocols (Courier,Modbus,IEC60870-5-103 or DNP3) +
IRIG-B (Modulated)
4
* Options are not available with software versions 32 or 34 except for 100Mbit/s variant with IEC 61850 and software version 35 or later (Design
P14xEd1-TM-EN-1
A1
