Loaded contact 1000 operations min.
Unloaded contact 10000 operations min.
Operate time < 5 ms
Reset time < 10 ms
10.4 HIGH BREAK OUTPUT CONTACTS
Compliance In accordance with IEC 60255-1:2009
Use For applciations requiring high rupture capacity
Rated voltage 300 V
Maximum continuous current 10 A DC
Short duration withstand carry
30 A DC for 3 s
250 A for 30 ms
Make and break, dc resistive 7500 W
Make and break, dc inductive 2500 W (L/R = 50 ms)
Make and carry, dc resistive 30 A for 3 s, 10000 operations (subject to the above limits)
Make, carry and break, dc resistive
30 A for 3 s, 5000 operations (subject to the above limits)
30 A for 200 ms, 10000 operations (subject to the abov
e limits)
Mak
e, carry and break, dc inductive
10 A for 40 ms, 10000 operations (subject to the above limits)
10 a for 20 ms (250V, 4 shots per second)
Loaded contact 10,000 operations minimum.
Unloaded contact 100,000 operations minimum.
Operate time < 0.2 ms
R
eset time < 8 ms
MOV Protection Maximum voltage 330 V DC
10.5 WATCHDOG CONTACTS
Use Non-programmable contacts for relay healthy/relay fail indication
Breaking capacity, dc resistive 30 W
Breaking capacity, dc inductive 15 W (L/R = 40 ms)
Breaking capacity, ac inductive 375 VA inductive (cos phi = 0.7)
P14x Chapter 23 - Technical Specifications
P14xEd1-TM-EN-1 553
