Servicing the PM880 8-3
August 2003
Printing Reports
When used with an IR-compatible printer, the PM880 can print
out a variety of data (current site, logs, drive contents, and user
functions, tables, and settings) in the Reports option. To enter the
Reports option, scroll to the Reports entry on the Service Menu
and press
[ENTER]. The screen appears similar to Figure 8-2
below.
Figure 8-2: The Reports Window
Press
[ENTER] to open the drop-down list of available reports, as
shown in Figure 8-2 above. Press the [
T]or [S] arrow keys to
scroll to the desired reports, and press
[ENTER]. Then press [F2]
(Print) to print out the desired reports, or press
[F3] (Exit) to leave
the option and return to Operate Mode. Figure 8-3 on the next
page shows a typical printout of a drive report.
Reports
Print
Exit
Current Site
Reports
Global Settings
Menu Commands
All Reports
All User Settings
User Functions
User Tables
Drive Contents
To Next Page
