August 2003
5-10 Displaying and Configuring Data
Specifying the Number of Displayed Parameters
As mentioned earlier, the PM880 can display one to four different
measurement parameters simultaneously. However, sometimes
you might wish to display only one or two parameters. To change
the number of open display windows from within the Site Menu
(shown in Figure 5-6 on page 5-9), use the [
T]or [S] arrow keys
to move to the desired number of views (1 View, 2 Views, etc.)
Press
[ENTER].
The screen displays the designated number of windows. For
example, Figure 5-7 below shows the screen displayed in Figure
5-3 on page 5-4, reconfigured for a single view.
Figure 5-7: Display Screen Configured for Single View
Note: The PM880 opens display windows clockwise from the
upper left; that is, if you press “1 View,” the parameter
displayed in the upper left window appears. If you press
“2 Views,” the parameters shown in the two top windows
appear. The view for “3 Views” adds the window in the
lower left, and that for “4 Views” adds the window in the
lower right.
2002/11/30 09:53 AM
Dew Point, °C
ABC.SIT
-150
10 Minutes
-50.0
50
15
-28
-72
-115
