GE PM880 User Manual

Programming Site Data 3-9
August 2003
Entering Pressure Calibration Data
To enter calibration data for the pressure transducer on the TF
Probe or MISP Probe, you must list the zero and span range in
mV (TF Probe) or FP (M2SP Probe) as well as the zero and span
range in PSIg or kPa.
1. To enter the Pressure window, press the [
X] arrow key to
reach the Pressure tab and press
[ENTER]. The screen appears
similar to Figure 3-4 below.
Figure 3-4: The Pressure Window in the Calibration
Option
2. Press the [
T] key to enter the first zero value (here shown as
mV) in the calibration table.
3. Press
[ENTER] to open the text box. Use the numeric keys to
enter the desired value, and press
[ENTER] to confirm the
entry.
4. Press the [
X] key to move to the Pressure text box (here
shown as kPa), and press
[ENTER]. Again, use the numeric
keys to enter the desired value, and press
[ENTER] to confirm
the entry.
5. Use the arrow keys to move to the Span boxes, and repeat
steps 3 and 4 to enter the Span values.
6. When you have completed entering values, press
[F3] (Exit).
The PM880 returns to the Pressure tab at the top of the screen.
Calibration - [0000000]
Exit
Hygro Pressure Saturation Probe ID
mV kPa
Zero
Span
0.00
0.00
0.00
0.00
