It is possible that the web browser will display a message advising that the certificate of the site was not found. If happens,
choose to continue in the site and then the HTTPS interface will be shown.
HTTP and HTTPS are the most friendly-to-use interfaces allowed, as it runs in a Web
browser interface. An example of the first screen interface when accessed by these
protocols is shown below.
Figure 80: Example of HTTP or HTTPS first screen at a given web browser
To access the software configuration via web browser for the first time, configure the
terminal for any address between 192.168.4.1 and 192.168.4.254 (except
192.168.4.88, which is the factory IP). Mask is 255.255.255.0 for local connection.
At Windows OS, follow the steps to change the terminal IP address:
Enter at Control Panel;
Choose the network connections option;
At the Local Connection Status, choose the Properties option;
At the Local Area Connection Properties, choose IP version 4 protocol;
After selecting IPv4, choose Properties;
At the General Tab, choose the Use the Following IP address option and
then type:
o IP address: any value from 192.168.4.1 to 192.168.4.254, except
Reason Switches default IP address 192.168.4.88;
o Subnet Mask: 255.255.255.0;
o Default gateway: leave it empty.
