GE S2020 User Manual

GE Reason Switches
Chapter 11 – Technical Specifications
REASON SWITCHES-TM-EN-3
301
10 Insulation, EMI and Environmental Tests
10.1 Insulation Tests
Description
Value
Insulation Class
Class I
10.2 Type Tests
Test
Description
Test Levels
IEC 61000-4-2
Electrostatic discharge immunity
6 kV contact / 8 KV air
IEC 61000-4-3
Radiated RFI
10 V/m
IEC 61000-4-4
Electrical fast transient
2 kV @5 kHz
IEC 61000-4-5
Surge immunity
Differential mode: 1 kV
Common mode: 2 kV
IEC 61000-4-6
Immunity to conducted disturbances induced
by radio-frequency fields
10 V
IEC 61000-4-8
Magnetic Field
30 A/m continuous – 300 A/m @ 1 s
IEC 61000-4-11
IEC 61000-4-29
Voltage dips, short interruptions and voltage
variations
AC and DC voltage dips
Test level: 0% residual voltage
Duration time AC: 1 cycle
DC: 16.6 ms
Test level: 40% residual voltage
Duration time AC: 12 cycles
DC: 200 ms
Test level: 70% residual voltage
Duration time AC: 30 cycles
DC: 500 ms
AC and DC voltage interruptions
Test level: 0% residual voltage
Duration time AC: 300 cycles
DC:5s
IEC 61000-4-17
Ripple on DC input power port immunity test
Test level: 1 % of rated DC value
Test frequency: 120 Hz, sinusoidal
waveform.
IEC 61000-4-18
Damped Oscillatory
Voltage oscillation frequency: 1 MHz
Differential mode: 1 kV peak voltage;
Common mode 2 kV peak voltage
Gradual Startup
Shut-down ramp: 60 s
Power off: 5 m Start-up ramp: 60 s
CISPR11:2009
Radiated emission
30 to 230 MHz – 50 dB (μV/m) quasi
peak at 3 m 230 to 1,000 MHz – 57 dB
(μV/m) quasi peak at 3 m
IEC 60068-2-1
Cold temperature
-40 °C, 16 Hours
IEC 60068-2-2
Dry heat temperature
+85 °C, 16 Hours
IEC 60068-2-30
Damp heat temperature, cyclic (12 + 12 h
cycle)
95% (non-condensing), 55 °C
IEC 60255-21-1
Mechanic vibration
2 g @ (10 - 150) Hz
IEC 60255-21-2
Mechanic shock and bump
15 g @ 11 mS
