GE S2020 User Manual

Chapter 1 – Introduction
GE Reason Switches
REASON SWITCHES-TM-EN-3
27
7.3 T1000
Variants
1-5 6 7 8 9 10 11 12 13 14 15 16 17-18 19-20
Model Type
T1000 Modular Managed Ethernet Switch Gigabit T1000
Power Supply 1
24-48 Vdc 1
100-250 Vdc / 110-240 Vac 3
Power Supply 2
24-48 Vdc 1
100-250 Vdc / 110-240 Vac 3
Not installed X
Mounting Options 1
Ethernet ports on the front F
Ethernet ports on the rear R
Mounting Options 2
Rack/Panel mounting P
DIN rail mounting D
Interface Module 1
Two 1 Gbps RJ45 copper 10/100BASE-TX/1000BASE-T Ethernet ports A
Two slots for SFP transceivers B
Two 1 Gbps LC-type connector multi mode fiber 1000BASE-SX Ethernet for up to 0.5 km C
Two 1 Gbps LC-type connector single mode fiber 1000BASE-LX Ethernet for up to 10 km D
Two 1 Gbps LC-type connector single mode fiber 1000BASE-ZX Ethernet for up to 40 km E
Two 1 Gbps LC-type connector single mode fiber 1000BASE-ZX Ethernet for up to 80 km F
Two 100 Mbps ST-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km G
Two 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km H
Two 1 Gbps RJ45 SFP Transceivers 10/100BASE-TX/1000BASE-T Ethernet ports (Not CE marked) J
Not installed X
Interface Module 2
Two 1 Gbps RJ45 copper 10/100BASE-TX/1000BASE-T Ethernet ports A
Two slots for SFP transceivers B
Two 1 Gbps LC-type connector multi mode fiber 1000BASE-SX Ethernet for up to 0.5 km C
Two 1 Gbps LC-type connector single mode fiber 1000BASE-LX Ethernet for up to 10 km D
Two 1 Gbps LC-type connector single mode fiber 1000BASE-ZX Ethernet for up to 40 km E
Two 1 Gbps LC-type connector single mode fiber 1000BASE-ZX Ethernet for up to 80 km F
Two 100 Mbps ST-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km G
Two 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km H
Two 1 Gbps RJ45 SFP Transceivers 10/100BASE-TX/1000BASE-T Ethernet ports (Not CE marked) J
Not installed X
Interface Module 3
Two 1 Gbps RJ45 copper 10/100BASE-TX/1000BASE-T Ethernet ports A
Two slots for SFP transceivers B
Two 1 Gbps LC-type connector multi mode fiber 1000BASE-SX Ethernet for up to 0.5 km C
Two 1 Gbps LC-type connector single mode fiber 1000BASE-LX Ethernet for up to 10 km D
Two 1 Gbps LC-type connector single mode fiber 1000BASE-ZX Ethernet for up to 40 km E
Two 1 Gbps LC-type connector single mode fiber 1000BASE-ZX Ethernet for up to 80 km F
Two 100 Mbps ST-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km G
Two 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km H
Two 1 Gbps RJ45 SFP Transceivers 10/100BASE-TX/1000BASE-T Ethernet ports (Not CE marked) J
Not installed X
Order Number

GE S2020 Specifications

General

Brand	GE
Model	S2020
Category	Switch
Language	English
