GE S2020 User Manual

Chapter 7 – Configuration
GE Reason Switches
REASON SWITCHES-TM-EN-3
229
 Filtering ingress process: this port should accept both
untagged and tagged frames;
 Egress process: egress process should be set to Untag
only frames with Port VLAN identifier.
Thus, configuration of the port where the switches are connected should be as
follows.
 Port mode should be chosen as Trunk port;
 Port VLAN should be 1;
 For trunk ports, Port Type is not allowed to be changed
from C-Port;
 For trunk ports, Ingress Filtering is not allowed to be
changed from enabled;
 For trunk ports, Ingress Acceptance is not allowed to be
changed from Tagged and Untagged;
 Egress tagging should be chosen as Untag Port VLAN;
 Allowed VLANs should be 1, 10, 20, 30;
 No forbidden VLANs should be configured.
These VLAN configuration settings should be enough to guarantee that only
equipment expecting to receive a given traffic will receive it. Besides, segregation of
traffic would increase the reliability of the network, as congestion on one VLAN would
not affect other ones.
14.2 RSTP Configuring in a Ring Network Topology
Consider the situation given figure below.
