Chapter 3 – Hardware Design
GE Reason Switches
REASON SWITCHES-TM-EN-3
43
4 Communication port connections
With up to 6 communication modules, the available Ethernet communication ports
for the T1000 are:
Connection
Transfer Rate
Number of Interfaces
ST
100BASE-FX
2 ports per module
RJ45
10/100/1000BASE-TX
2 ports per module
SFP
100/1000BASE-FX
2 ports per module
ST connector is allowed only in T1000 Switch.
With up to 5 communication modules, the available Ethernet communication ports
for the S2020 are:
Connection
Transfer Rate
Number of Interfaces
RJ45
10/100/BASE-TX
4 ports per module
SFP
100BASE-FX
4 ports per module
S2020 switch also allows up to 4 Gigabit interfaces (1000BASE-TX or 1000BASE-FX) at the module 01
(first communication module position). The remaining 16 interfaces, divided in four communication
modules, must be Fast Ethernet.
With up to 6 communication modules, the available Ethernet communication ports
for the S2024G are:
Connection
Transfer Rate
Number of Interfaces
RJ45
10/100/1000BASE-TX
4 ports per module
SFP
100/1000BASE-FX
4 ports per module
A
B
C
