8 MAC Table
This section describes MAC Address presented in the web interface for monitoring
purposes.
If desired to update Reason Switches web screen automatically, check the Auto
Refresh checkbox on top to perform it. If selected, monitoring web page will be
updated after 3 seconds of the last update automatically.
MAC Address Table:
MAC Address table presents the current address table being used by the switch.
Rows at the table indicate entries of the MAC table, and columns organize
information displayed. This table is used for forwarding decision by a bridge.
o Type, which indicates type of the learning process. Ports
configured as Auto will be displayed as Dynamic learning type, and
Ports configured as Secure will be displayed as Static learning type
port;
o VLAN identifier (VID) of the MAC address;
o MAC Address mapped and included at the MAC Table;
o Port members, divided in column per port. If a specific MAC address
can be member of a given port, the symbol will be marked at this
MAC address row and Port column.
