GE Reason Switches
REASON SWITCHES-TM-EN-3
25
7 Ordering Options
7.1 S2020
Issue F
Variants Order Number
1-5 6 7 8 9 10 11 12 13 14-15 16-17
Model Type
S2020 Modular Managed Ethernet Switch S2020
Power Supply 1
24-48 Vdc 1
100-250 Vdc / 110-240 Vac 3
Power Supply 2
24-48 Vdc 1
100-250 Vdc / 110-240 Vac 3
Not installed X
Mounting Options
19” Rack Mount / Rear Mount P
Interface Module 1
Four 1 Gbps RJ45 copper 10/100BASE-TX/1000BASE-T Ethernet ports A
Four slots for SFP transceivers B
Four 1 Gbps LC-type connector multi mode fiber 1000BASE-SX Ethernet for up to 0.5 km C
Four 1 Gbps LC-type connector single mode fiber 1000BASE-LX Ethernet for up to 10 km D
Four 1 Gbps LC-type connector single mode fiber 1000BASE-ZX Ethernet for up to 40 km E
Four 1 Gbps LC-type connector single mode fiber 1000BASE-ZX Ethernet for up to 80 km F
Four 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km H
Four RJ45 copper 10/100BASE-TX I
Four 1 Gbps RJ45 SFP Transceivers 10/100BASE-TX/1000BASE-T Ethernet ports (Not CE marked) J
Two 1 Gbps RJ45 SFP Transceivers 10/100BASE-TX/1000BASE-T Ethernet ports + Two 1 Gbps LC-type connector multi mode fiber 1000BASE-SX Ethernet for up to 0.5 km K
Two 1 Gbps RJ45 SFP Transceivers 10/100BASE-TX/1000BASE-T Ethernet ports + Two 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km
L
Two 1 Gbps LC-type connector multi mode fiber 1000BASE-SX Ethernet for up to 0.5 km + Two 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km M
Not installed X
Interface Module 2
Four slots for SFP transceivers B
Four 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km H
Four RJ45 copper 10/100BASE-TX I
Not installed X
Interface Module 3
Four slots for SFP transceivers B
Four 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km H
Four RJ45 copper 10/100BASE-TX I
Not installed X
Interface Module 4
Four slots for SFP transceivers B
Four 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km H
Four RJ45 copper 10/100BASE-TX I
Not installed X
Interface Module 5
Four slots for SFP transceivers B
Four 100 Mbps LC-type connector multi mode fiber 100BASE-FX Ethernet for up to 2 km H
Four RJ45 copper 10/100BASE-TX I
Not installed X
Firmware Version
Latest available firmware - 06 06
Firmware version number - 05 05
Hardware Design Suffix
Standard hardware release B
Alternate hardware release BL
