D
IRECTION 5813707-100, REVISION 2 VENUE GO™ SERVICE MANUAL
3-36 Chapter 3 - System Setup
PRELIMINARY
5.) Select Use the following IP address and proceed as follows (refer to Figure 3-23):
• In the IP address field type: 10.0.0.1
• In the Subnet mask field type: 255.0.0.0
6.) Tap OK and click Close.
The Venue Go™ system’s IP address is defined.
3-6-5 Software Options Configuration
3-6-5-1 Software Option Introduction
A Software Option Key, an alphanumeric text string, enables a software option or a combination of
software options.
The Software Option Key is specific for each unit.
NOTE: There may be more than one Software Option Key in use, depending on the installed options.
3-6-5-2 To Install a Software Option
Follow these steps to install the Software Option Key:
1) Log on as adm.
2) Select Admin (lower part of window).
3) Select the System Admin tab.
4) Select New to open the New Key dialog where you type the SW Option Key.
5) Type the Software Option Key.
You must include the dashes (-) as they are part of the Software Option Key.
6) Press Save to save the new setting.
7) Restart to save and activate the settings and adjustments you have done so far.
3-6-5-3 Remote Check and Configurations
Contact the Online Center for InSite checkout.
Incorrect Software Option Key entry will result in loss of
Ultrasound system options. If Software Option Key is
incorrect, please contact your local GE Service
Representative or the Online Center.
