D
IRECTION 5813707-100, REVISION 2 VENUE™ SERVICE MANUAL
8-50 Chapter 8 - Replacement Procedures
PRELIMINARY
8-2-20 Cart Tray Replacement Procedure
8-2-20-1 Tools
Phillips screwdriver of appropriate size
8-2-20-2 Time Required
5 min
8-2-20-3 Preparations
1.) Shut down the Venue Go™ ultrasound unit, as described in Power Shutdown .
2.) Prepare stable flat surface covered with a soft material (such as foam) to prevent scratches to the
display.
3.) Dismount Venue Go™ system from cart and place it on a previously prepared surface with the
display facing down.
8-2-20-4 Cart Tray Removal Procedure
4.) Dismount the system from the cart.
5.) Remove the cradle assembly.
6.) Remove the tilt assembly.
7.) Remove the cart bin.
8.) Remove the printer assembly.
Refer to Table 9-16 on page 9-17.
• Dismounting System on Cart
• Cradle Assembly Removal Procedure
• Cradle Tilt Removal Procedure
• Cart Bin Removal Procedure
• Printer Assembly Removal Procedure
To Next Page
