IRECTION 5813707-100, REVISION 2 HAWAII™ SERVICE MANUAL
Chapter 5 - Venue Go™Components and Function (Theory) 5-21
PRELIMINARY
Section 5-11
Peripherals
5-11-1 Internal Peripheral
5-11-1-1 Wi-Fi Adapter
The Wi-Fi adapter allows the user to connect the system to network wirelessly.
The Wi-Fi adapter is connected internally to the C-BEB.
5-11-2 External Peripherals
5-11-2-1 Barcode reader
The barcode reader is an option. It allows the user scanning patient ID from a printed barcode label and
scanning needle type barcode.
The barcode reader is connected to the Venue Go™ system via a USB port located on the rear.
5-11-2-2 Black & White Digital Graphic Printer
The B/W Printer is available as an option and is powered by a dedicated AC/DC power supply. The
printer is mounted on the cart of the Venue™ ultrasound scanner.
5-11-2-3 ECG
The ECG module is responsible for the acquisition of the ECG Analog signal inputs by the three leads
connected to the patient body.
Section 5-12
Options
• For a list of the available options, see Peripherals on page 9 - 14.
• For descriptions of the options, see the User Manual.
• For Installation instructions, see: Options Setup on page 3 - 63.
• For configuration, see: Options Setup on page 3 - 63.
