D
IRECTION 5813707-100, REVISION 2 VENUE GO™ SERVICE MANUAL
3-2 Chapter 3 - System Setup
PRELIMINARY
Section 3-2
Setup Reminders
3-2-1 Average Setup Time
The Venue Go™ setup and functional checkout will take approximately one hour; Venue Go™
consoles with optional equipment may take slightly longer.
Once the site has been prepared, the average installation time required is shown in Tab le 3 -9 below.
3-2-2 Setup Warnings
1.) The Venue Go™ ultrasound scanner weighs approximately 6 Kgs (13.22 lbs), without add-ons/
peripherals. System cart weighs approximately 27 kg (59.5 lbs).
Two people are always required to unpack the system cart.
2.) There are no operator-serviceable components. To prevent shock, do not remove any covers or
panels. If problems or malfunctions occur, unplug the power cord. Only qualified service personnel
should carry out servicing and troubleshooting.
NOTE: For information on shipping carton labels, refer to Figure 3-3 on page 3-5 and Figure 3-4 on
page 3-6.
3-2-2-1 System Acclimation Time
Following transport, the Venue Go™ system may be very cold, or hot. Allow time for the system to
acclimate before being switched ON. Acclimation requires 1 hour for each 2.5
o
C increment, when the
temperature of the system is below 10
o
C or above 40
o
C.
6
Table 3-8 Average Setup Time
Description
Average
Setup Time
Comments
Unpacking the scanner
15 minutes
Setting up the scanner
30 minutes Time may vary, according to the required configuration
DICOM Option
(connectivity)
30 minutes Time may vary, according to the required configuration
Setting up InSite
30 minutes
Turning the system ON after arrival at the site - without allowing time for acclimation - may
cause system damage!
Table 3-9 Venue Go™ System Acclimation Time
°C
-40 -35 -30 -25 -20 -15 -10 -5 0 5 10 35 40 45 50 55 60
°F
-40 -31 -22 -13 -4 5 14 23 32 41 50 95 104 113 122 131 140
Hrs
20 18 16 14 12 10 8 4 2 0 0 0 2 4 6 8
