D
IRECTION 5813707-100, REVISION 2 VENUE GO™ SERVICE MANUAL
4-18 Chapter 4 - General Procedures and Functional Checks
PRELIMINARY
4-3-6 Peripheral Checks
4-3-6-1 Printer Checks
The internal printer is controlled from the Print button on the Venue Go™ ’s application main screen.
Tab le 4 -3 outlines the steps for performing Printer checks.
4-3-6-1-1 Windows Print Test Page
This checks that the printer is correctly installed and hooked up at the Windows level.
1) On the Venue Go™ application main screen, tap: Settings > Config > Connectivity > Additional
Outputs.
Table 4-24 Printer Checks
Step Task Expected Result(s)
1
When scanning in 2D Color
Mode, press Freeze to stop
image acquisition.
Image scanning stops with the last
picture on the screen.
2
Press Print on the Operator
Panel
The image displayed on the screen is
printed on the assigned printer.
3
Check if the print quality on the
pictures from both printers are of
expected quality.
To Next Page
