D
IRECTION 5813707-100, REVISION 2 VENUE GO™ SERVICE MANUAL
Chapter 3 - System Setup 3-37
PRELIMINARY
Section 3-7
Connectivity Overview
3-7-1 Physical Connection
There are several possible connection methods, as outlined below.
3-7-2 Stand-alone Venue Go™
No network connection needed.
3-7-3 Wired Ethernet from Venue Go™ to a Workstation
Either of these situations may apply:
• Direct Cable Connection from Venue Go™ to a workstation via a Crossover Cable.
You will only need a Crossover Cable for network (TCP/IP) use to connect the two units this way.
a.) Connect one end of the crossed network cable to the network connector on the Venue Go™ .
b.) Connect the other end to the network connector to the Workstation.
• Connection via a Peer-to-Peer network.
You will need a network hub or network router and one network cable for each unit connected to
the hub.
• Connection via Hospital Network.
You will need one network cable to connect the Venue Go™ to a wall jack on the hospital’s
network.
