D
IRECTION 5813707-100, REVISION 2 VENUE GO™ SERVICE MANUAL
Chapter 3 - System Setup 3-19
PRELIMINARY
To connect a probe to one of the sockets 1, 2, or 3:
1) Hold the probe connector vertically with the cable pointing upward.
2.) Prior to inserting the probe, ensure that the connector locking handle is positioned to the left.
3) Align the connector with the probe port and carefully push into place.
4) Push the connector locking handle to the right to secure the probe connector.
5) Carefully position the probe cord so it is free to move and is not resting on the floor.
3-5-5-3 Disconnect Probes
Follow these steps to disconnect the RS probes, as applicable:
1) Move the connector locking lever to the left to unlock the connector.
2) Carefully remove the connector from the port.
3) Ensure that the probe head is clean before placing the probe in its storage case.
For cleaning instructions, see the User Manual.
3-5-6 Power on/Boot up
For procedure, see: Power ON/Boot-up on page 4 - 3.
3-5-7 Power Shut Down
For procedure, see: Power Shutdown on page 4 - 5.
3-5-8 Complete Power Down
For procedure, see: Complete Power Down on page 3 - 19.
