ADV200 WA • Quick start up guide - Specification and installation 101
9.6 Output electrical data
U2 Max output voltage ����������������0,94 x Uln (Uln =AC Input voltage)
f2 Max output frequency ���������������500 Hz (Sizes 1015 ... 72500) , 200 Hz (≥ Size 73550):
see section 9.3.3 for more details.
Braking IGBT Unit ��������������������Standard internal (with external resistor. except ADV200
WA-...-DC models); braking torque 150 % MAX
Sizes Inverter Output Pn mot (Recommended asynchronous motor output)
Heavy duty
(KVA)
Light duty
(KVA)
Heavy duty Light duty
@400 Vac
(kW)
@460 Vac
(Hp)
@400 Vac
(kW)
@460 Vac
(Hp)
1015 1.7 3.0 0.75 1 1.5 2
1022
3.0 4.0 1.5 2 2.2 3
1030 4.0 5.3 2.2 3 3 5
1040 5.3 6.6 3.0 5 4 5
1055
6.6 9 4.0 5 5.5 7.5
2075 9 11.4 5.5 7.5 7.5 10
2110
11.4 15.9 7.5 10 11 15
2150
15.9 21.5 11 15 15 20
3185 21.5 26.3 15 20 18.5 25
3220
26.3 32 18.5 25 22 30
3300 32 43 22 30 30 40
4370 43 52 30 40 37 50
4450
52 60 37 50 45 60
4550
60 73 45 60 55 75
5750 73 104 55 75 75 100
5900 104 125 75 100 90 125
51100 125 145 90 125 110 150
61320 145 173 110 150 132 175
61600
173 208 132 175 160 200
72000 208 267 160 200 200 250
72500 267 319 200 250 250 300
73150 319 409 250 300 315 400
73550 409 450 315 400 355 450
74000 450 506 355 450 400 500
500 kW 506 603 400 500 500 650
630 kW 603 776 500 650 630 850
710 kW 776 852 630 850 710 950
800 kW 852 956 710 950 800 1100
1000 kW 1108 1247 900 1200 1000 1300
1200 kW 1247 1420 1000 1300 1200 1600
