gefran ADV200 WA DC Series User Manual

ADV200 WA • Quick start up guide - Specification and installation 107
9.8 Cooling
All the Drives have internal fans.
Sizes
Dissipated power
Airflow of fan
W
Heatsink (m
3
/h) Internal (m
3
/h)
1015 60 32 26
1022 90 32 32
1030 100 32 32
1040 120 32 32
1055 160 32 32
2075 200 32 32
2110 250 56 x 2 32
2150 300 56 x 2 32
3185 380 80 x 2 32
3220 460 80 x 2 32
3300 600 80 x 2 32
4370 900 2 x 250 2 x 50
4450 1000 2 x 250 2 x 50
4550 1290 2 x 250 2 x 50
5750 1760 2 x 285 1 x 170
5900 2150 2 x 355 2 x 170
51100 2400 2 x 355 2 x 170
61320 2850 3 x 310 2 x 170
61600 3600 3 x 310 2 x 170
72000 3900 1500 -
72500 4000 1500 -
73150 5200 1500 -
73550 6000 2000 -
74000 6500 2000 -
500 kW
ADV200-WA-72500-KXX-4-MS 05 -SI
4000 1500 -
ADV200-WA-72500-XXX-4-SL
4000 1500 -
630 kW
ADV200-WA-73150-KXX-4-MS 06 -SI
5200 1500 -
ADV200-WA-73150-XXX-4-SL
5200 1500 -
710 kW
ADV200-WA-73550-KXX-4-MS 07 -SI
6000 2000 -
ADV200-WA-73550-XXX-4-SL
6000 2000 -
800 kW
ADV200-WA-74000-KXX-4-MS 08 -SI
6500 2000 -
ADV200-WA-74000-XXX-4-SL
6500 2000 -
1000 kW
ADV200-WA-73550-KXX-4-MS 10 -SI
6000 2000 -
ADV200-WA-73550-XXX-4-SL
6000 2000 -
ADV200-WA-73550-XXX-4-SL
6000 2000 -
1200 kW
ADV200-WA-74000-KXX-4-MS 12 -SI
6500 2000 -
ADV200-WA-74000-XXX-4-SL
6500 2000 -
ADV200-WA-74000-XXX-4-SL
6500 2000 -
