62 ADV200 WA • Quick start up guide - Specification and installation
This function permits access to any parameter entering only the software number
of the parameter (PAR).
When the parameter reached by the “Goto” command is displayed, it is possible
to navigate all the parameters forming part of the same group using the ▲ and ▼
keys.
Pressing the ► key returns to the “Goto” function.
To exit the “Goto” function, press the ► key.
6.3 Parameter modication
To enter parameter modication mode, press the E key when the parameter to be
modied is displayed.
To save the value of the parameter, following modication, press the E key again.
Note ! To save permanently, see paragraph 6.4.
To exit from modication mode without saving the value, press the ESC key.
The operations to be carried out to modify the value depend on the type of the
parameter, as described below.
Note ! For further information about the type of parameters displayed, see chapter Parameters List (ADV200
WA FP manual).
● Numeric parameters
T+ T- EN LOC ILim n:0 AL
13 DIGITAL OUTPUTS
14 ANALOG INPUTS
15 ANALOG OUTPUTS
16 MOTOR DATA
E
T+ T- EN LOC ILim n:0 AL
1 6 . 0 1
PA R : 2 0 0 0
Rated voltage
+400
V
Def: +400
T+ T- EN LOC ILim n:0 AL
1 6 . 0 1
PA R : 2 0 0 0
Rated voltage
+
V
Def: +400
000000400
When E is pressed to access modication mode, the cursor is activated on the
digit corresponding to the unit.
Using the ◄ and ► keys, the cursor can be moved to all the digits, including trail-
ing zeros that are normally not displayed.
With the ▲ and ▼ keys, the digit under the cursor is increased or decreased.
Press E to conrm the modication or ESC to cancel.
● Binary parameters (BIT type)
The parameter may assume only two states which are indicated as OFF-ON or
0-1.
X 5
T+ T- EN LOC ILim n:0 AL
10 SPEED MONITOR FUNC
11 COMMANDS
12 DIGITAL INPUTS
13 DIGITAL OUTPUTS
E
T+ T- EN LOC ILim n:0 AL
1 3 . 0 5
PA R : 1 3 3 0
Di
g
out 1 inversion
ON
T+ T- EN LOC ILim n:0 AL
1 3 . 0 5
PA R : 1 3 3 0
Di
g
out 1 inversion
OFF
Pressing E, modication mode is activated. The entire line is displayed in reverse.
Use the ▲ and ▼ keys to move from one state to another.
Press E to conrm the modication or ESC to cancel.
