gefran ADV200 WA DC Series User Manual

ADV200 WA • Quick start up guide - Specification and installation 13
2.1 Drive type designation
The main technical characteristic of the drive are showed in the product code and
in the nameplate. I.e. product code:
ADV200-WA 1 040 -K B X -4 -XX YY -DC -SI
Safety card EXP-SFTy-ADV included
DC bus power supply version
Parallel version only:
XX : MS = MASTER
SL = SLAVE
YY :
05 = 500.0 kW
06 = 630.0 kW
07 = 710.0 kW
08 = 800.0 kW
10 = 1000.0 kW
12 = 1200.0 kW
Rated voltage :
4 = 400 Vac 4A = 460 Vac
Software: X = standard
Braking unit:
X = non included
B = included
Keypad:
X = not included
K = included
Drive power, in kW:
015 = 1.5 kW
022 = 2.2 kW
030 = 3.0 kW
040 = 4.0 kW
055 = 5.5 kW
075 = 7.5 kW
110 = 11.0 kW
150 = 15.0 kW
185 = 18.5 kW
220 = 22.0 kW
300 = 30.0 kW
370 = 37.0 kW
450 = 45.0 kW
550 = 55.0 kW
750 = 75.0 kW
900 = 90.0 kW
1100 = 110.0 kW
1320 = 132.0 kW
1600 = 160.0 kW
2000 = 200.0 kW
2500 = 250.0 kW
3150 = 315.0 kW
3550 = 355.0 kW
4000 = 400.0 kW
Mechanical drive sizes:
1 = size 1
2 = size 2
3 = size 3
4 = size 4
5 = size 5
6 = size 6
7 = size 7
Drive ADV200 WA series
Identication Nameplate
Type : ADV200-WA-1055 -KBX-4 S/N: 07012345
Inp: 400Vac-15% 500Vac +5% 50/60Hz 3Ph
11.1A@400Vac 10A@480Vac
Out : 0-480Vac 500Hz 3Ph 5,5kW@400Vac 7,5 Hp @ 460Vac
÷
5.5kW 13A @400V 11,7A@460V Ovld.110%-60s
4kW 9,5A @400V 8,6A@460V Ovld.150%-60s
Drive model
Serial number
Input (mains supply, frequency, AC Input
Current at constant torque)
Output (Output voltage, frequency, power,
current, CT and VT overloads)
Approvals
Made in Italy
Firmware & cards revision level nameplate
Firmware HW release S/N 07012345 Prod.
Release
D F P R S BU SW . CFG
CONF
Cards revision
Firmware revision
Power
Regulation
Safety
Braking unit
Software
revision
Product
configuration
2.00 -.G -.L 10.10.10 A2
