26 ADV200 WA • Quick start up guide - Specification and installation
5.1 Power section
5.1.1 Cable Cross Section
Sizes
Terminals: L1 - L2 - L3 - BR1 - BR2 - C - D - U - V - W
Maximum Cable Cross Section (flexible conductor) Recommended stripping Tightening torque (min)
(mm
2
) AWG (mm) (Nm)
1015
4 10 7 0,5 ... 0,6
1022
4 10 7 0,5 ... 0,6
1030
4 10 7 0,5 ... 0,6
1040
4 10 7 0,5 ... 0,6
1055
4 10 7 0,5 ... 0,6
2075
6 8 10 0,7 ... 0,8
2110
6 8 10 1,2 ... 1,5
2150
6 7 12 1,5 ... 1,7
3185
16 6 14 1,5 ... 1,7
3220
16 6 14 1,5 ... 1,7
3300
16 6 14 1,5 ... 1,7
4370
35 2 18 2,4 ... 4,5
4450
35 2 18 2,4 ... 4,5
4550
35 2 18 2,4 ... 4,5
5750
95 (BR1/BR2=50) 4/0 (BR1/BR2=1/0) 23 (BR1/BR2=27) 14 (BR1/BR2=10)
5900
95 4/0 23 14
51100
95 4/0 23 14
61320
150 300 30 24
61600
240 500 40 40
Sizes
Bars: L1 - L2 - L3 - C - D - U - V - W
Recommended cable cross-section Lock screw diameter Tightening torque (min)
(mm
2
) AWG / kcmil (mm) (Nm)
72000 - 72500
2 x 100 2 x AWG 4/0 M10 50
73150
2 x 150 2 x kcmil 300 M10 50
73550 - 74000
2 x 185 2 x kcmil 350 M10 50
Sizes
Connection on mechanical cabinet
Cable Cross Section Lock screw
diameter
Recommended
terminal
Tightening torque
(mm
2
) AWG / kcmil (mm) (mm) (Nm)
1015 ... 1030 16 AWG 6 M5 Eyelet - Spade 6
1040 ... 4550 16 AWG 6 M6 Eyelet - Spade 10
5750 ... 51100 50 AWG 1/0 M6 Eyelet - Spade 10
61320 75 AWG 2/0 M8 Eyelet - Spade 24
61600 120 250 kcmil M8 Eyelet - Spade 24
Connection on bars
72000 ... 73150 150 300 kcmil M10 Eyelet 50
73550 - 74000 185 350 kcmil M10 Eyelet 50
