132 ADV200 WA • Quick start up guide - Specification and installation
Appendix 1 - Parallel connection (500 ... 1200kW sizes)
A 1.1 Introduction
To obtain a drive of more than 400 kW connect a number of single units of be-
tween 250 kW and 400 kW in parallel.
A parallel connection of several drives basically consists of one MASTER unit and
one or more SLAVE units.
Power code Description (Designation) code Description (Designation)
500kW
S9O25WM ADV200-WA-72500-KXX-4-MS 05 -SI S9O25WMC ADV200-WA-72500-KXX-4- MS 05-DC- SI
S9O25WS ADV200-WA-72500-XXX-4-SL S9O25SWMC ADV200-WA-72500-KXX-4- SL-DC
630kW
S9O26WM ADV200-WA-73150-KXX-4-MS 06 -SI S9O26WMC ADV200-WA-73150-KXX-4-MS 06-DC-SI
S9O26WS ADV200-WA-73150-XXX-4-SL S9O26WSC ADV200-WA-73150-KXX-4-SL-DC
710kW
S9O27WM ADV200-WA-73550-KXX-4-MS 07 -SI S9O27WMC ADV200-WA-73550-KXX-4-MS 07-DC-SI
S9O27WS ADV200-WA-73550-XXX-4-SL S9O27WSC ADV200-WA-73550-KXX-4-SL-DC
800kW
S9O28WM ADV200-WA-74000-KXX-4-MS 08 -SI S9O28WMC ADV200-WA-74000-KXX-4- MS 08-DC-SI
S9O28WS ADV200-WA-74000-XXX-4-SL S9O28WSC ADV200-WA-74000-KXX-4- SL-DC
1000kW
S9O27WM1 ADV200-WA-73550-KXX-4-MS 10 -SI S9O27WM2 ADV200-WA-73550-KXX-4-MS 10-DC-SI
S9O27WS ADV200-WA-73550-XXX-4-SL S9O27WSC ADV200-WA-73550-KXX-4-SL-DC
S9O27WS ADV200-WA-73550-XXX-4-SL S9O27WSC ADV200-WA-73550-KXX-4-SL-DC
1200kW
S9O28WM1 ADV200-WA-74000-KXX-4-MS 12 -SI S9O28WM2 ADV200-WA-74000-KXX-4- MS 12-DC-SI
S9O28WS ADV200-WA-74000-XXX-4-SL S9O28WSC ADV200-WA-74000-KXX-4- SL-DC
S9O28WS ADV200-WA-74000-XXX-4-SL S9O28WSC ADV200-WA-74000-KXX-4- SL-DC
710kW
S9O29WM ADV200-WA-73550-KXX-4A-MS 07-SI S9O29WMC ADV200-WA-73550-KXX-4A-MS 07-DC-SI
S9O29WS ADV200-WA-73550-KXX-4A -SL S9O29WSC ADV200-WA-73550-KXX-4A -SL-DC
800kW
S9O30WM ADV200-WA-74000-KXX-4A- MS 08-SI S9O30WMC ADV200-WA-74000-KXX-4A- MS 08-DC-SI
S9O30WS ADV200-WA-74000-KXX-4A- SL S9O30WSC ADV200-WA-74000-KXX-4A- SL-DC
1000kW
S9O29WM1 ADV200-WA-73550-KXX-4A-MS 10-SI S9O29WM2 ADV200-WA-73550-KXX-4A-MS 10-DC-SI
S9O29WS ADV200-WA-73550-KXX-4A -SL S9O29WSC ADV200-WA-73550-KXX-4A -SL-DC
S9O29WS ADV200-WA-73550-KXX-4A -SL S9O29WSC ADV200-WA-73550-KXX-4A -SL-DC
1200kW
S9O30WM1 ADV200-WA-74000-KXX-4A- MS 12-SI S9O30WM2 ADV200-WA-74000-KXX-4A- MS 12-DC-SI
S9O30WS ADV200-WA-74000-KXX-4A- SL S9O30WSC ADV200-WA-74000-KXX-4A- SL-DC
S9O30WS ADV200-WA-74000-KXX-4A- SL S9O30WSC ADV200-WA-74000-KXX-4A- SL-DC
Master unit
this is the only one to have the regulation card and keypad. It differs from the
standard single unit in that the power section control card (INT-P-ADV) is recon-
gured to function as MASTER and includes one or more MASTER - SLAVE (INT-
SLAVE) interface cards, one card for each slave that is connected.
The MASTER - SLAVE interface is achieved via a specic signal cable included in
the SLAVE drive packaging.
Slave unit
It differs from the standard single unit in that it has a dedicated power section
control card (INT-P-ADV) and there is no regulation card or keypad.
INT-P-ADV-MASTER card
The INT-P-ADV-MASTER card provided with one or more INT-SLAVE cards, acts
as the interface between the R-ADV regulation card and the power section of the
master unit and all the slave units. It also performs the following functions:
• current signal scaling (via dip switch, factory-set)
