126 ADV200 WA • Quick start up guide - Specification and installation
10.3 External EMC lter (optional)
ADV200 WA series inverters are equipped with an internal EMI (except ADV200
WA-...-DC models) lter able to guarantee the performance levels required by EN
61800-3 standard (according to 2nd environment, category C3) with a maximum
of 20 meters of shielded motor cable (up to 50 metres for size 5 and above).
Optional external lters for different installations are listed in the table below.
Sizes
AC mains voltage 400V -15% … 480V +10%
Heavy duty Light duty
EN 61800-3 :
Category / Environment /
Motor cable length
Type Code Type Code
1015 EMI FTF-480-7 S7GHL EMI FTF-480-7 S7GHL C2 / 1st / 30 m
1022 EMI FTF-480-7 S7GHL EMI FTF-480-7 S7GHL C2 / 1st / 30 m
1030 EMI FTF-480-7 S7GHL EMI FTF-480-7 S7GHL C2 / 1st / 30 m
1040 EMI FTF-480-7 S7GHL EMI FTF-480-16 S7GHO C2 / 1st / 30 m
1055 EMI FTF-480-16 S7GHO EMI FTF-480-16 S7GHO C2 / 1st / 30 m
2075 EMI FTF-480-16 S7GHO EMI FTF-480-16 S7GHO C2 / 1st / 30 m
2110 EMI FTF-480-16 S7GHO EMI FTF-480-30 S7GHP C2 / 1st / 30 m
2150 EMI FTF-480-30 S7GHP EMI FTF-480-30 S7GHP C2 / 1st / 30 m
3185 EMI FTF-480-30 S7GHP EMI FTF-480-42 S7GOA C2 / 1st / 30 m
3220 EMI FTF-480-42 S7GOA EMI FTF-480-55 S7GOB C2 / 1st / 30 m
3300 EMI FTF-480-55 S7GOB EMI FTF-480-75 S7GOC C2 / 1st / 30 m
4370 EMI FTF-480-75 S7GOC EMI FTF-480-75 S7GOC C2 / 1st / 30 m
4450 EMI FTF-480-75 S7GOC EMI FTF-480-100 S7GOD C2 / 1st / 30 m
4550 EMI FTF-480-100 S7GOD EMI FTF-480-130 S7GOE C2 / 1st / 30 m
5750 EMI FTF-480-130 S7GOE EMI FTF-480-180 S7GOF C3 / 2° / 100 m
5900 EMI FTF-480-180 S7GOF EMI FTF-480-180 S7GOF C3 / 2° / 100 m
51100 EMI FTF-480-180 S7GOF EMI-480-250 S7DGG C3 / 2° / 100 m
61320 EMI-480-250 S7DGG
EMI-480-250 S7DGG
C3 / 2° / 100 m
61600 EMI-480-250 S7DGG EMI-480-320 S7DGH C3 / 2° / 100 m
72000 EMI-480-400 S7DGI EMI-480-400 S7DGI C3 / 2° / 100 m
72500 EMI-480-400 S7DGI EMI-480-600 S7DGL C3 / 2° / 100 m
73150 EMI-480-600 S7DGL EMI-480-600 S7DGL C3 / 2° / 100 m
73550 EMI-480-600 S7DGL EMI-480-800 S7DGM C3 / 2° / 100 m
74000 EMI-480-800 S7DGM EMI-480-800 S7DGM C3 / 2° / 100 m
