80 ADV200 WA • Quick start up guide - Specification and installation

7.2 First customized start-up

In this section a startup test is performed, using a standard conguration, to check

drive functioning and command connections.

A programming sequence has to be run to achieve a rst simple customisation in

order to be able to set the drive for the requested application.

Note ! The main sections to be used, depending on the desired conguration, are

described below.

• Typical connection diagrams

Auxiliary control circuits �� see chapter 5.5, gure 5.5.1

Typical connection diagram, connection through terminals strip �� see chapter 5.5, gure 5.5.2

Potentials of the control section, Digital I/O PNP connection �� see chapter 5.2.4, gure 5.2.4.1

Other inputs connections (NPN-PNP) �� see chapter 5.2.4, gure 5.2.4.2

NPN outputs connection �� see chapter 5.2.4, gure 5.2.4.3

• Digital inputs

The table on chapter 5.2.3 shows the default settings for the analog and digital

inputs and outputs.

Note ! Digital input settings can only be edited from the Expert parameters, see chapter 6.5.2.

• Selecting the regulation mode

First set the regulation mode in the Regulation mode parameter (04 DRIVE CON-

FIG menu, PAR: 552) :

0 V/f control. This is the simplest and least advanced control mode. This mode

can also be used to control several motors connected in parallel using a single

drive.

1 Open loop eld-oriented vector control (Flux vector OL). In this mode,

once the motor parameter self-tuning procedure has been performed, it is

possible to create a mathematical model on which to perform all the neces-

sary calculations in order to obtain high performance levels, especially high

motor torque levels, even at very low speeds without the use of feedback, and

achieve signicant dynamic performance.

• Selecting the type of reference

After setting the regulation mode, the source of the speed reference must be set in

the Ramp ref 1 src parameter (05 REFERENCES menu, PAR: 610). This source

can be selected from among those listed in the L_MLTREF selection list:

1 Analog input 1 mon parameter (PAR: 1500) to use the signal applied to

terminals 1 – 2 of analog input 1 (14 - ANALOG INPUTS menu).

2 Dig ramp ref 1 parameter (05 - REFERENCES menu, PAR: 600) to set a

digital speed inside the drive.

3 Multi ref out mon parameter (07 - MULTI REFERENCE menu, PAR: 852) to

select the digital speeds using the digital inputs of the drive.

4 Mpot output mon parameter (08 - MOTOPOTENTIOMETER menu, PAR:
