ADV200 WA • Quick start up guide - Specification and installation 99
9.5 Input electrical data
9.5.1 AC power supply
AC Input voltage, Uln �����������������3 ph 380 Vac -15% ... 500 Vac +5%,
AC Input frequency �������������������50/60 Hz, ± 2%
Choke �����������������������������integrated (DC) up to size 61600
Total harmonic distortion (THD) ���������40% Light duty, 50% Heavy duty (at nominal current)
Connection to TT and TN Networks �������yes, standard version
Connection to IT Networks �������������yes, special version ADV200 WA...-IT only (upon request).
Sizes
ADV200 WA-...-4 versions (Motor cos phi 0.9 @ 400 Vac)
AC Input current
Heavy duty (Arms) Light duty (Arms)
1015 2.1 3.7
1022 3.7 4.9
1030 4.9 6.5
1040 6.5 8.1
1055 8.1 11.1
2075 11.1 14.0
2110 14.0 19.6
2150 19.6 26.4
3185 26.4 32.3
3220 32.3 39
3300 39 53
4370 53 64
4450 64 74
4550 74 89
5750 100 143
5900 143 171
51100 171 200
61320
200 238
61600 238 285
72000 300 350
72500 350 420
73150 420 580
73550 580 640
74000 640 710
500 kW 665 800
630 kW 800 1100
710 kW 1100 1215
800 kW 1215 1350
1000 kW 1650 1800
1200 kW 1800 2020
