18 ADV200 WA • Quick start up guide - Specification and installation
4.2 Fastening positions
Taglia 3
Size 3
150 [5.91”]
500.1 [19.7”]
(A)
No. 4 screw 5MA
(B)
(A)
120 [4.72”]
Taglia 2
Size 2
376.6 [14.83”]
Taglia 1
Size 1
No. 4 screw 5MA
(B)
100 [3.94”]
306.4 [12.06”]
Fissaggio a muro
Wall mounting
(A)
126.2 [4.97”]
364.4 [14.33”]
320 [12.6”]
82 [3.23”]
(B)
No. 4 screw 5MA
156.2 [6.15”]
392 [15.43”]
440 [17.32”]
135 [5.31”]
187.6 [7.4”]
557 [21.93”]
517 [20.35”]
110 [4.33”]
Taglia 4
Size 4
220 [8.66”]
612 [24.09”]
595 [23.43”]
(A)
(B)
No. 4 screw 6MA
268 [10.55”]
682 [26.85”]
267 [10.51”]
Fissaggio a muro
Wall mounting
No. 5 screw 6MA
Taglia 6
Size 6
Taglia 5
Size 5
(B)
(A)
(B)
(A)
No. 4 screw 6MA
422 [16.61”]
350 [13.78”]
175 [6.89”]
836 [32.91”]
175 [6.89”]
853 [33.58”]
311 [12.24”]
220 [8.66”]
853 [33.58”]
748 [29.45”]
265 [10.43”]
