128 ADV200 WA • Quick start up guide - Specification and installation
10.4 Braking resistor (optional)
Recommended resistors for use with internal braking unit (except ADV200 WA-DC
models):
Sizes List and technical data of standard external resistors
Resistor type Code Max Overload
energy,
1”- duty-cycle
10%
Ebr (kJ)
Max Overload
energy,
30”- duty-cycle
25%
Ebr (kJ)
Braking
resistor
nominal
power
Pnbr (W)
Resistance
value
Rbr (Ω)
Enclosure
1015
RF 220 T 100R S8T0CE 1.5 11 220 100 IP44
1022
RF 220 T 100R S8T0CE 1.5 11 220 100 IP44
1030
RF 300 DT 100R S8T0CB 2.5 19 300 100 IP44
1040
RF 300 DT 100R S8T0CB 2.5 19 300 100 IP44
1055
RFPD 750 DT 100R S8SY4 7.5 38 750 100 IP44
2075
RFPD 750 DT 68R S8T0CD 7.5 38 750 68 IP44
2110
RFPD 900 DT 68R S8SY5 9 48 900 68 IP44
2150
RFPD 1100 DT 40R S8SY6 11 58 1100 40 IP44
3185
RFPR 1900 D 28R S8SZ5 19 75 1900 28 IP44
3220
BRT4K0-15R4 S8T00G 40 150 4000 15.4 IP20
3300
BRT4K0-15R4 S8T00G 40 150 4000 15.4 IP20
4370
BRT4K0-11R6 S8T00H 40 150 4000 11.6 IP20
4450
BRT4K0-11R6 S8T00H 40 150 4000 11.6 IP20
4550
BRT8K0-7R7 S8T00I 40 150 8000 7.7 IP20
5750
BRT8K0-7R7 S8T00I 40 150 8000 7.7 IP20
≥ 5900 and
ADV200 WA-
...-DC
External braking unit (BUy series, optional)
Braking resistors may be subject to unexpected overloads due to faults.
Resistors MUST be protected using thermal cutouts. These devices must not interrupt the
circuit in which the resistor is inserted but their auxiliary contact must cut off the power
supply to the power section of the drive. If the resistor requires a protection contact, this
must be used together with that of the thermal cutout.
A la suite de pannes, les résistances de freinage peuvent être sujettes à des surcharges impré-
vues. La protection des résistances au moyen de dispositifs de protection thermique est absolu-
ment capitale. Ces dispositifs ne doivent pas interrompre le circuit qui abrite la résistance, mais
leur contact auxiliaire doit couper l’alimentation du côté puissance du drive. Si la résistance
prévoit un contact de protection, ce dernier doit être utilisé conjointement à celui du dispositif de
protection thermique.
Note ! Resistors dimensions and weights are listed in the Gefran Accessories catalogue (1S9I09).
