ADV200 WA • Quick start up guide - Specification and installation 65
Menu 04 DRIVE CONFIG, parameter 04.16 Display backlight, PAR : 576.
Sets lighting of the display
ON the light of the display remains always on.
OFF (default) the light switches off after approx. 3 minutes from pressing of
the last key.
6.6 Alarms
The alarms page is displayed automatically when an alarm occurs.
T+ T- EN LOC ILim n:0 AL
2
Alarm
-R T N : 1 / 2
Power down
1
3
4
Time: 28:04
Code: 0000H-0
1 Alarm: identies the alarm page.
RTN : indicates that the alarm has been reset; if the alarm is still active, noth-
ing is displayed.
x/y : x indicates the position of this alarm in the list of alarms and y the number
of alarms (the alarm with lowest x is the most recent)
2 Description of the alarm
3 Sub-code of the alarm, provides other information in addition to the description
4 Moment of occurrence of the alarm in machine time.
The list of alarms is scrolled using the ▲ and ▼ keys.
6.6.1 Alarm reset
● If the alarm page is displayed:
Pressing the RST key, the alarms are reset and all alarms reset are eliminated
from the list.
If, after this operation, the list of alarms is empty, the alarm page is closed.
If the list is not empty, press the ► key to exit from the alarms page.
● If the alarms page is not displayed:
Pressing the RST key, the alarms are reset.
If active alarms are still present following reset, the alarm page is opened.
Note ! For further information, see chapter 8.2.
6.7 Messages
Operator messages are displayed with this page.
The messages are of two types:
- timed (closed automatically after a certain number of seconds),
- xed (remain displayed until the operator presses the ESC key).
Several concurrent messages are enqueued and presented to the operator in
sequence, starting from the most recent.
