98 ADV200 WA • Quick start up guide - Specification and installation
Speed format (1) ���������������������32 bit
Frequency range ���������������������± 2000 Hz
(1) referred to Full scale speed, PAR:680.
Sizes Max frequency Min frequency
FVOL VF FVOL VF
1015 ... 72500
150 Hz 500 Hz
0.5 Hz 1 Hz
73150 ... 1200 kW
150 Hz 200 Hz
9.3.4 Torque control
Torque resolution (2) �����������������> 0.1 %
Direct torque control ������������������yes
Current limitation ��������������������Limits ±, Limits mot/gen, Limits variable
(2) referred to rated torque
9.3.5 Overload
Heavy duty (HD) ���������������������150% 60 sec, 180% 0,5 sec.
Light duty (LD) ����������������������110% 60 sec.
9.4 DC circuit
Overvoltage threshold (Overvoltage) ������820 Vdc
Undervoltage threshold (Undervoltage) ����380 Vdc
