118 ADV200 WA • Quick start up guide - Specification and installation

10.1.2 External fuses of the power section DC input side (F2)

The following fuses must be used with an external DC power supply or regenerative

converter (for further details refer to the converter instruction manual):

Sizes

F2 - External fuses for DC input side

EUROPE AMERICA

Type Code Type Code

1015 ... 1030 GRD2/10 F4D13 A70P10 S7G49

1040 GRD2/16 F4D14 A70P20-1 S7G48

1055 GRD2/20 F4D15 A70P20-1 S7G48

2075 GRD2/20 F4D15 A70P30-1 S7I50

2110 GRD3/35 F4D20 A70P40 S7G52

2150 GRD3/50 F4D21 A70P50 S7G53

3185 ... 3300 S00C+/üf1/80/80A/690V F4EAF A70P80 S7G54

4370 S00C+/üf1/80/100A/690V F4G18 A70P100 S7G55

4450 S00C+/üf1/80/125A/690V F4EAJ A70P150 S7G56

4550 S00C+/üf1/80/160A/690V F4EAL A70P150 S7G56

5750 S00/üf1/80/200A/690V F4G23 A70P200 S7G58

5900 S1üf1/110/250A/690V F4G28 A70P250 S7G59

51100 S1üf1/110/315A/690V F4G30 A70P350 S7G61

61320 S2üf1/110/400A/690V F4G34 A70P400 S7G62

61600 - 72000 S2üf1/110/500A/690V F4E30 A70P500 S7G63

72500 S2üf1/110/630A/690V F4E31 A70P600 S7G65

73150 S3üf1/110/800A/690V F4H02 A70P800 S7813

73550 - 74000 S3üf1/110/1000A/690V F4H03 A70P1000 S7812

500 kW

ADV200-WA-72500-KXX-4-MS 05 -SI

S2üf1/110/630A/690V F4E31 A70P600 S7G65

ADV200-WA-72500-XXX-4-SL

S2üf1/110/630A/690V F4E31 A70P600 S7G65

630 kW

ADV200-WA-73150-KXX-4-MS 06 -SI

S3üf1/110/800A/690V F4H02 A70P800 S7813

ADV200-WA-73150-XXX-4-SL

S3üf1/110/800A/690V F4H02 A70P800 S7813

710 kW

ADV200-WA-73550-KXX-4-MS 07 -SI
