ADV200 • Functions description and parameters list 119
P
n
= 160 kW
Max Speed = 1500 rpm (ω
max
= 1500 * 2π / 60 = 157.08 rad/s)
Initial speed = 70% (ω
0
=1050 * 2π / 60 = 110 rad/s)
η
mot
= 0.96
η
inv
= 0.98
J = 5 kgm
2
T
load
= Negligible for Constant Torque app
0,5 = Internal Coefcient
P
loss_max
= 0.5 * (1 – η
mot
) * P
n
+ (1- η
inv
)*P
n
P
loss_max
= 0.5 * (1- 0.96) * 160000 + (1-0.98)*160000 = 6400 W
decTime > ( J * ω
max
* ω0 ) / (P
loss_max
)
Considering negligible T
load
value for constant torque applications, the resulting minimum deceleration value will
be:
decTime > ( 5 * 157.08 * 110 ) / ( 6400 ) = 13.5 s
Nota! The braking action of the applied load and friction can contribute to reduce the minimum time of deceleration. This further reduc-
tion depends on the characteristics of the load. For variable torque application, the reduction could be substantial. Contact Gefran
for application support.
