188 ADV200 • Functions description and parameters list

28 - RECIPE CONFIG

Lets you create a custom menu from the keypad (or from GF_eXpress), composed of a maximum of 20 parameters

(menu 29 - RECIPE).

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

28.1 6300 Recipe config 1 UINT16 0 0 0 RW FVS

28.2 6302 Recipe config 2 UINT16 0 0 0 RW FVS

28.3 6304 Recipe config 3 UINT16 0 0 0 RW FVS

28.4 6306 Recipe config 4 UINT16 0 0 0 RW FVS

28.5 6308 Recipe config 5 UINT16 0 0 0 RW FVS

28.6 6310 Recipe config 6 UINT16 0 0 0 RW FVS

28.7 6312 Recipe config 7 UINT16 0 0 0 RW FVS

28.8 6314 Recipe config 8 UINT16 0 0 0 RW FVS

28.9 6316 Recipe config 9 UINT16 0 0 0 RW FVS

28.10 6318 Recipe config 10 UINT16 0 0 0 RW FVS

28.11 6320 Recipe config 11 UINT16 0 0 0 RW FVS

28.12 6322 Recipe config 12 UINT16 0 0 0 RW FVS

28.13 6324 Recipe config 13 UINT16 0 0 0 RW FVS

28.14 6326 Recipe config 14 UINT16 0 0 0 RW FVS

28.15 6328 Recipe config 15 UINT16 0 0 0 RW FVS

28.16 6330 Recipe config 16 UINT16 0 0 0 RW FVS

28.17 6332 Recipe config 17 UINT16 0 0 0 RW FVS

28.18 6334 Recipe config 18 UINT16 0 0 0 RW FVS

28.19 6336 Recipe config 19 UINT16 0 0 0 RW FVS

28.20 6338 Recipe config 20 UINT16 0 0 0 RW FVS

Conguration parameters for creating custom menu.

Select a Recipe cong X parameter, press Enter and insert the IPA of the parameter to be added to the cus-

tom list (will be available on menu 29 - RECIPE).

To remove an IPA from the list of custom menus, set the related parameter Recipe cong X = 0.

When settings are done, use the “Save parameters” command on the DRIVE CONFIG menu to save in per-

manent memory.

29 - RECIPE

The parameters congured on menu 28 - RECIPE CONFIG. are written on the RECIPE menu (initially empty).
