ADV200 • Functions description and parameters list 189

PARAMETERS ON SELECTION LISTS, BUT NOT DISPLAYED ON KEYPAD

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

220 Theta ref mon INT32 0.0 0.0 0.0 ER

Monitor value of the electrical motor angle.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

224 Flux ref mon INT32 0.0 0.0 0.0 ER

Monitor value of the Flux reference.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

262 Motor speed nofilter FF INT16 16 0 0 0 ER

This parameter indicates the unltered motor speed.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

362 Drive overload trip BIT 16 0 0 1 ER

This signal indicates that the drive is in the overload condition. In the default condition the alarm is not triggered

as the relative action is set to Ignore.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

366 Drive overload 80 BIT 16 0 0 1 ER

This signal indicates that the drive has reached 80% of the thermal image accumulator (drive overload).

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

626 Ramp ref out mon FF INT16 16 0 0 0 ER

This parameter displays the reference value output of the ramp reference function block.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

760 Ramp out mon FF INT16 16 0 0 0 ER

This parameter displays the reference value output of the ramp function block.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

764 Ramp acc state BIT 16 0 0 1 ER

This signal indicates whether the acceleration ramp is active.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

766 SRamp dec state BIT 16 0 0 1 ER

This signal indicates whether the deceleration ramp is active.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

934 Ref is 0 BIT 16 0 0 1 ER

This signal is active when the reference is below the limit set in parameter 930 Reference 0 threshold.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

936 Ref is 0 delay BIT 16 0 0 1 ER

This parameter is active when the reference is below the threshold set in parameter 930 Reference 0 thresh-

old. The signal is enabled after the delay set with parameter 932 Reference delay 0.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

938 Ref is 0 Vf limit BIT 16 0 0 1 ER
