ADV200 • Functions description and parameters list 125
Procedures for setting up and managing the double parameter set
Creating the second set:
This function copies parameter set 0 onto set 1. Before enabling management of the double parameter set, the
rst set should be programmed with the correct values.
When the rst set is ready, the second can be activated as follows:
1 Activate management of the double parameter set by enabling parameter 3300 Par set enable.
2 Copy set 0 onto set 1 using command 3306 Par set 0 to 1 copy.
This creates an initial parameter base in set 1 to which changes can be made.
Save the parameters.
3 Activate set 1 using parameter 3302 Par set select src.
To select set 1 manually, set this parameter to “One”.
Otherwise select the desired source.
4 Modify the parameters in set 1 as necessary.
5 Save the parameters.
You can change the set being used by changing the source selected in parameter 3302 Par set select src.
This can only be changed with the drive disabled.
When the double parameter set is active, the number of the set being used is shown next to the number of
each parameter on the keypad.
Modifying and saving parameters:
When the double parameter set is active, any parameters that need to be the same in the two sets must be
modied in each set separately.
Parameters are only saved in the set that is active at the time. To save both sets, you must rst save one and
then select and save the other.
Note ! Any changes to the parameters regarding the “parameter sets”, performed when enabled, will be lost at the next switching unless
a Par set 0 to 1 copy command is sent. To save data permanently (even when the drive is switched off), send the Save param-
eters command (DRIVE CONFIG menu).
22.9 – FUNCTIONS/SPEED CAPTURE
This function allows the drive to capture a motor running due to inertia or driven by the load. The function is
also enabled in case of an automatic restart after an alarm condition.
Main elds of application:
- Capturing a motor set in motion by the load (for example pump motors driven by the uid)
- Capturing a motor connected directly to the power mains
- Capturing a motor running due to temporary disabling of the drive
- Capturing a motor that is running in the case of an automatic restart after an alarm
Note ! If the drive is enabled with the motor running and this function disabled, the drive could be blocked due to the intervention of the
Overcurrent or Undercurrent protections
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.9.1 3350 Speed capture ENUM Disable 0 1 ERW FV_
This parameter is used to enable the function to capture a motor that is running.
0 Disable
1 Alarm restart
2 Enable&restart
If set to 0 the capture running motor function is disabled. The output frequency starts from 0 and passes to the set
reference value using the ramp. If the drive is enabled with the motor running and this function disabled, the drive
could be disabled due to the intervention of the Overcurrent or Undercurrent protections.
If set to 1 the capture running motor function is executed at restart each time an alarm is automatically reset.
If set to 2 the capture running motor function is executed each time the drive is enabled and each time an alarm is
automatically reset.
This function is available with Regulation mode = Flux vector CL (asynchronous and synchronous motors) or V/f
control (asynchronous motors).
