ADV200 • Functions description and parameters list 157
23.2 – COMMUNICATION/FIELDBUS CONFIG
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.1 4000 Fieldbus type ENUM Off 0 5 RW FVS
Setting of the type of eldbus to be used.
0 Off
1 CanOpen
2 DeviceNet
3 Probus
10 DS402
30 Prodrive
40 Rte
If set to 0 no eldbus is selected.
If set to 1 the CanOpen eldbus prole is selected.
If set to 2 the ProBus-DP eldbus prole is selected.
If set to 3 the DeviceNet eldbus prole is selected.
If set to 10 the DS402 eldbus is selected.
If set to 30 the Prodrive eldbus is selected.
If set to 40 the Real Time Ethernet eldbus is selected.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.2 4004 Fieldbus baudrate ENUM 500k 0 12 RW FVS
Setting of the communication network speed (Baud Rate).
0 Auto
1 125k
2 250k
3 500k
4 1M
5 9600
6 19200
7 93750
8 187.5k
9 1.5M
10 3M
11 6M
12 12M
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.3 4006 Fieldbus address INT16 3 0 255 RW FVS
Setting of the node address of the drive when connected to the network.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.4 4010 Fieldbus M->S enable ENUM Enable 0 1 ERWZ FVS
Setting of eldbus data updating.
0 Disable
1 Enable
If set to 0, the possibility of sending commands and references from the drive PLC via the eldbus is disabled.
If set to 1 the possibility of sending commands and references from the drive PLC via the eldbus is enabled.
