88 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.2.16 5352 Encoder 1 err code UINT32 0 0 0 ER FVS
This parameter contains a hexadecimal code that supplies information on the type of error that occurred.
Error values are the same (and have the same signicance) as the ones indicated in parameter IPA 2172 Spd-
FbkLoss code.
17.3 - ENCODER/ENCODER 2
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.3.1 5100 Encoder 2 pulses ppr UINT16 CALCI CALCI CALCI ERWZ FVS
Setting of the number of impulses/rev of the incremental encoder mounted in slot 1 or 3.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.3.2 5102 Encoder 2 supply V FLOAT 5.2 5.2 CALCF ERWZ FVS
Setting of the encoder supply voltage supplied by the relative optional card. Min and max values refer to the
incremental digital encoder cards with one or two encoders.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.3.3 5104 Encoder 2 input cfg ENUM TTL 0 1 ERWZ FVS
Setting of the input conguration of the incremental digital encoder, TTL or HTL.
0 HTL
1 TTL
The value of this parameter is automatically set in HTL when the value entered in the Encoder 2 supply pa-
rameter is more than 6.0V.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.3.4 5106 Encoder 2 repetition ENUM
No division
0 3 ERWZ FVS
Setting of the divider to apply to the encoder repetition output frequency.
0 No division
1 Divide 2
2 Divide 4
3 Divide 8
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.3.5 5108 Encoder 2 signal Vpp V FLOAT 1.0 0.8 1.2 ERWZ FVS
Setting of the encoder 2 signal peak-to-peak voltage value. Incremental sinusoidal encoders and absolute
SinCos encoders normally produce signals with a peak-to-peak voltage of 1 Vpp. Due to voltage drops along
the cable, the signal may have a lower peak-to-peak voltage when it reaches the feedback card, triggering the
Speed fbk loss alarm.
This parameter is used to congure the value of the peak-to-peak voltage of the incremental sinusoidal encod-
ers and absolute SinCos encoders on the input terminals of the feedback card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.3.6 5110 Encoder2signal check ENUM Contr A-B 0 3 ERWZ FVS
Conguration of which channels of the incremental digital encoder 2 must be controlled for processing the
Speed fbk loss [22].
0 Check disabled
1 Check A-B
2 Check A-B-Z
4 Check A-B-SE
