ADV200 • Selection lists 289

PAR Description Menu PAR Description Menu PAR Description Menu

G – SELECTION LISTS

L_ANOUT

6000 Null (*)

626 Ramp ref out mon (*)

628 Ramp setpoint 1.7

760 Ramp out mon (*)

664 Speed setpoint 1.8

260 Motor speed 1.9

262 Motor speed nolter (*)

2150 Encoder 1 speed 17.2.13

5150 Encoder 2 speed 17.3.13

250 Output current 1.1

252 Output voltage 1.2

254 Output frequency 1.3

256 Output power 1.4

280 Torque current ref 1.19

282 Magnet current ref 1.20

284 Torque current 1.21

286 Magnet current 1.22

2360 Torque lim Pos Inuse 20.9

2362 Torque lim Neg Inuse 20.10

2386 Torque ref % 20.18

2388 Torque ref nolter (*)

2394 Torque % 20.20

2396 Torque nolter (*)

270 DC link voltage 1.10

3006 Speed ratio out mon (*)

3070 Droop out mon 22.2.5

852 Multi ref out mon 7.24

870 Mpot setpoint 8.1

894 Mpot output mon 8.13

920 Jog output mon 9.6

3104 Inertia comp mon 22.3.3

1500 Analog input 1 mon 14.1

1550 Analog input 2 mon 14.17

1600 Analog input 1X mon 14.33

1650 Analog input 2X mon 14.45

368 Drive overload accum 1.24

3212 Motor overload accum 1.23

3260 Bres overload accum 1.25

2232 Spd reg P gain Inuse 18.11

2234 Spd reg I gain Inuse 18.12

2246 Speed reg P factor 18.16

2248 Speed reg I factor 18.17

3446 Powerloss nextratio (*)

4024 Fieldbus M->S1 mon 23.3.3

4034 Fieldbus M->S2 mon 23.3.7

4044 Fieldbus M->S3 mon 23.3.11

4054 Fieldbus M->S4 mon 23.3.15

4064 Fieldbus M->S5 mon 23.3.19

4074 Fieldbus M->S6 mon 23.3.23

4084 Fieldbus M->S7 mon 23.3.27

4094 Fieldbus M->S8 mon 23.3.31

4104 Fieldbus M->S9 mon 23.3.35

4114 Fieldbus M->S10 mon 23.3.39

4124 Fieldbus M->S11 mon 23.3.43

4134 Fieldbus M->S12 mon 23.3.47

4144 Fieldbus M->S13 mon 23.3.51

4154 Fieldbus M->S14 mon 23.3.55

4164 Fieldbus M->S15 mon 23.3.59

4174 Fieldbus M->S16 mon 23.3.63

3700 Pad 1 22.12.1

3702 Pad 2 22.12.2

3704 Pad 3 22.12.3

3706 Pad 4 22.12.4

3708 Pad 5 22.12.5

3710 Pad 6 22.12.6

3712 Pad 7 22.12.7

3714 Pad 8 22.12.8

3716 Pad 9 22.12.9

3718 Pad 10 22.12.10

3720 Pad 11 22.12.11

3722 Pad 12 22.12.12

3724 Pad 13 22.12.13

3726 Pad 14 22.12.14

3728 Pad 15 22.12.15

3730 Pad 16 22.12.16

5008 Test gen out 27.1.5

5750 FL Fwd 1 mon 23.8.13

5752 FL Fwd 2 mon 23.8.14

5754 FL Fwd 3 mon 23.8.15

5756 FL Fwd 4 mon 23.8.16

5758 FL Fwd 5 mon 23.8.17

5760 FL Fwd 6 mon 23.8.18

5762 FL Fwd 7 mon 23.8.19

5764 FL Fwd 8 mon 23.8.20

5800 FL Fwd 1 inv mon (*)

5802 FL Fwd 2 inv mon (*)

5804 FL Fwd 3 inv mon (*)

5806 FL Fwd 4 inv mon (*)

5808 FL Fwd 5 inv mon (*)

5810 FL Fwd 6 inv mon (*)

5812 FL Fwd 7 inv mon (*)

5814 FL Fwd 8 inv mon (*)

4538 KTY84/PTC current (*)

2346 Torque current ref 1 20.15

2342 Working load 1.18

L_CMP

XXXX (1)
