158 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.5 4012 Fieldbus alarm mode INT32 0 0 1 ERWZ FVS
Setting of the Opt Bus Fault alarm generation mode.
0 Off
1 On
If set to 0 the alarm is only generated if the drive is enabled.
If set to 1 the alarm is generated even with the drive disabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.6 4014 Fieldbus state ENUM Stop 0 9 R FVS
The logic status of the eldbus connection is displayed. The value depends on the type of bus that is used.
The following logic states are displayed if the CANopen or Rte eldbus is selected:
0 Stop
1 PreOperational
2 Operational
The following logic states are displayed if the Probus eldbus is selected:
3 Error
4 WaitPRM
5 WaitCFG
6 DataExchange
7 DPError
The following logic states are displayed if the Rte eldbus is selected:
8 SafeOp
9 Init
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.7 4398 RTE protocol ENUM None 0 6 ER FVS
The Real Time Ethernet protocol implemented on the expansion card is displayed.
0 None
1 Ethercat
2 EthernetIP
3 GdNet
4 Pronet
5 ModbusTCP (Not available)
6 Powerlink (Not available)
107 Prodrive
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.8 5608 IP address UINT32 0 0 4294967295 ER FVS
Display of DCP address set via conguration of Pronet node.
23.3 – COMMUNICATION/FIELDBUS M2S
Conguration of input data
There are 16 groups of parameters, with the same structure, for conguring data to be exchanged cyclically with the
eldbus. Each group permits the exchange of a single datum, which corresponds to a single drive parameter.
The data written by the Master (a PLC, PC or control panel) to the Slave (the drive) can be congured in the COMMU-
NICATION/FIELDBUS M2S menu, hence the name of the M->S menu:
