GREE Multi Variable Air Conditioners Indoor Unit
94
3 Installation of Indoor Unit
3.1 Installation of Low Static Pressure Duct Type Indoor Unit
3.1.1 Outline and Installation Dimension
The following diagram is applicable for units with the cooling capacity ranging from 7k Btu/h to
22kBtu/h.
The following table lists the detailed dimensions.
Unit: mm(inch)
Item
Model
A
B
C
D
E
F
G
H
I
GMV-ND07PLS/A-T(U)
GMV-ND09PLS/A-T(U)
GMV-ND12PLS/A-T(U)
742
(29 3/16)
491
(19 5/16)
700
(27-1/2)
615
(24-1/4)
200
(7-7/8)
121
(4-3/4)
528
(20-13/16)
161
(6-5/16)
580
(22-13/16)
GMV-ND14PLS/A-T(U)
942
(37-1/16)
491
(19-5/16)
900
(35-3/8)
615
(24-1/4)
200
(7-7/8)
121
(4-3/4)
728
(28-11/16)
161
(6-5/16)
780
(30-11/16)
GMV-ND18PLS/A-T(U)
GMV-ND22PLS/A-T(U)
1142
(44-15/16)
491
(19-5/16)
1100
(43-1/4)
615
(24-1/4)
200
(7-7/8)
121
(4-3/4)
928
(36--9/16)
161
(6-5/16)
980
(38-9/16)
