Gree GMV-ND07PLS/A-T(U) User Manual

GREE Multi Variable Air Conditioners Indoor Unit
28
Model
GMV-ND09T
S/A-T(U)
GMV-ND12T
S/A-T(U)
GMV-ND15T
S/A-T(U)
GMV-ND18T
S/A-T(U)
GMV-ND24T
S/A-T(U)
Pipe
Connection
Liquid Side
mm
Φ6.35
Φ6.35
Φ6.35
Φ9.52
Φ9.52
inch
Φ1/4
Φ1/4
Φ1/4
Φ3/8
Φ3/8
Gas Side
mm
Φ9.52
Φ12.7
Φ12.7
Φ15.9
Φ15.9
inch
Φ3/8
Φ1/2
Φ1/2
Φ5/8
Φ5/8
Drain Pipe
mm
Φ25
Φ25
Φ25
Φ25
Φ25
inch
Φ1
Φ1
Φ1
Φ1
Φ1
Power Supply
1-phase 208/230V 60Hz
1-phase 208/230V 60Hz
Fan
Type × Quantity
Centrifugal×3
Centrifugal×3
Centrifugal×3
Centrifugal×3
Centrifugal×3
Driving Mechanism
Direct-driven
Motor Type
BLDC
Motor Power
Input
W
55
55
55
55
91
Motor Running
Current
A
0.6
0.6
0.6
0.6
0.7
Airflow
Rate(H/M/L)
CFM
490/355/312
490/355/312
490/355/312
490/355/312
650/483/448
m
3
/h
830/600/530
830/600/530
830/600/530
830/600/530
1100/820/76
0
Sound Pressure Level(H/M/L)
dB(A)
35/33/31
35/33/31
35/33/31
35/33/31
39/37/35
Heat Exchanger
/
Air Filter
PP
Insulation Material
Foamed polystyrene
Refrigeration Control Device
EXV
Protection Device
Fuse
Panel name
TE01
TE01
TE01
TE01
TE01
4.8 Floor Ceiling Type Indoor Unit
Model
GMV-ND09ZD/A
-T(U)
GMV-ND12ZD/A
-T(U)
GMV-ND18ZD/A
-T(U)
GMV-ND24ZD/A
-T(U)
Product Code
CM600N0420
CM600N0430
CM600N0440
CM600N0450
Cooling Capacity
Btu/h
9500
12000
18000
24000
kW
2.8
3.5
5.3
7.0
Heating Capacity
Btu/h
10500
13500
20000
27000
kW
3.1
4.0
5.9
7.9
Casing Finish
Galvanized Steel plate
Dimensions
(W×D×H)
Outline
mm
1220×700×225
1220×700×225
1220×700×225
1420×700×245
inch
48×27-9/16
×8-7/8
48×27-9/16
×8-7/8
48×27-9/16
×8-7/8
55-7/8×27-9/16
×9-5/8
Packaging
mm
1343×823×315
1343×823×315
1343×823×315
1548×828×345
inch
52-7/8×32-3/8
×12-3/8
52-7/8×32-3/8
×12-3/8
52-7/8×32-3/8
×12-3/8
60-15/16×32-5/8
×13-9/16
Net Weight
lbs.
88
88
88
110
kg
40
40
40
50
Gross Weight
lbs.
108
108
108
128
kg
49
49
49
58
Pipe
Connection
Liquid Side
mm
Φ6.35
Φ6.35
Φ9.52
Φ9.52
inch
Φ1/4
Φ1/4
Φ3/8
Φ3/8
Gas Side
mm
Φ9.52
Φ12.7
Φ15.9
Φ15.9
inch
Φ3/8
Φ1/2
Φ5/8
Φ5/8
Drain Pipe
mm
Φ17
Φ17
Φ17
Φ17
inch
Φ11/16
Φ11/16
Φ11/16
Φ11/16
