Gree GMV-ND07PLS/A-T(U) User Manual

GREE Multi Variable Air Conditioners Indoor Unit
21
Model
GMV-ND24T
/A-T(U)
GMV-ND30T
/A-T(U)
GMV-ND36T
/A-T(U)
GMV-ND42T
/A-T(U)
GMV-ND48T
/A-T(U)
Sound Pressure Level(H/M/L)
dB(A)
38/36/33
40/38/35
41/38/36
43/41/38
43/41/38
Heat Exchanger
Fenestrate plain film --hydrophilic film
Air Filter
PP
PP
PP
PP
PP
Insulation Material
Foamed
polystyrene
Foamed
polystyrene
Foamed
polystyrene
Foamed
polystyrene
Foamed
polystyrene
Refrigeration Control Device
EXV
EXV
EXV
EXV
EXV
Protection Device
Fuse
Fuse
Fuse
Fuse
Fuse
Panel Name
TC01
TC01
TC01
TC01
TC01
4.4 Wall Mounted Type Indoor Unit
Model
GMV-N07G/
A3A-D(U)
GMV-N09G/
A3A-D(U)
GMV-N12G/
A3A-D(U)
GMV-N18G/
A3A-D(U)
GMV-N24G/
A3A-D(U)
Product Code
CM100N1480
CM100N1490
CM100N1500
CM100N1510
CM100N1520
Cooling Capacity
Btu/h
7500
9500
12000
18000
24000
kW
2.2
2.8
3.5
5.2
7
Heating Capacity
Btu/h
8500
11000
13500
20000
25500
kW
2.5
3.2
4
5.8
7.5
Casing Finish
Galvanized Steel plate
Dimensions
(W×D×H)
Outline
mm
843×180×275
843×180×275
940×200×298
940×200×298
1008×221×319
inch
33-3/16×7-1/16
×10-13/16
33-3/16×7-1/16
×10-13/16
37×7-7/8
×11-3/4
37×7-7/8
×11-3/4
37×7-7/8
×11-3/4
Packaging
mm
973×258×370
973×258×370
1068×288×395
1068×288×395
1131×398×328
inch
38-5/16
×10-3/16
×14-9/16
38-5/16
×10-3/16
×14-9/16
42-1/16
×11-5/16
×15-9/16
42-1/16
×11-5/16
×15-9/16
42-1/16
×11-5/16
×15-9/16
Net Weight
lbs.
22.1
22.1
27.6
27.6
33.1
kg
10
10
12.5
12.5
15
Gross Weight
lbs.
27.6
27.6
34.2
34.2
40.8
kg
12.5
12.5
15.5
15.5
18.5
Pipe
Connections
Liquid Side
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ9.52
inch
Φ1/4
Φ1/4
Φ1/4
Φ1/4
Φ3/8
Gas Side
mm
Φ9.52
Φ9.52
Φ12.7
Φ12.7
Φ15.9
inch
Φ3/8
Φ3/8
Φ1/2
Φ1/2
Φ5/8
Drain Pipe
mm
Φ20
Φ20
Φ20
Φ20
Φ30
inch
Φ4/5
Φ4/5
Φ4/5
Φ4/5
Φ1 1/6
Power supply
1-phase 208/230V 60Hz
Fan
Type × Quantity
Cross-flow×1
Cross-flow×1
Cross-flow×1
Cross-flow×1
Cross-flow×1
Driving Mechanism
Direct-driven
Motor Type
PG
Motor Power
Input
W
50
50
60
60
70
Motor Running
Current
A
0.2
0.2
0.21
0.21
0.31
Airflow
Rate(H/M/L)
CFM
295/247/206
295/247/206
370/324/283
370/324/283
440/353/294
m
3
/h
500/420/350
500/420/350
630/550/480
630/550/480
750/600/500
Sound Pressure Level(H/M/L)
dB(A)
38/34/30
38/34/30
44/41/38
44/41/38
44/41/38
Heat Exchanger
Fenestrate plain film -- hydrophilic film
Air Filter
PP+10%BCM+FP03
Insulation Material
Foamed polystyrene
Refrigeration Control Device
EXV
Protection Device
Fuse
