Gree GMV-ND07PLS/A-T(U) User Manual

GREE Multi Variable Air Conditioners Indoor Unit
33
Model
GMV-ND07T/
B-T(U)
GMV-ND09T/
B-T(U)
GMV-ND12T/
B-T(U)
GMV-ND15T/
B-T(U)
GMV-ND18T/
B-T(U)
Fan
Type × Quantity
Centrifugal×1
Centrifugal×1
Centrifugal×1
Centrifugal×1
Centrifugal×1
Driving Mechanism
Direct-driven
Direct-driven
Direct-driven
Direct-driven
Direct-driven
Motor Type
BLDC
BLDC
BLDC
BLDC
BLDC
Motor Power Input
W
35
35
35
45
45
Motor Running
Current
A
0.4
0.4
0.4
0.5
0.5
Airflow
Rate(H/M/L)
CFM
355/295/235
355/295/235
355/295/235
410/355/283
410/355/283
m
3
/h
600/500/400
600/500/400
600/500/400
700/600/480
700/600/480
Sound Pressure Level(H/M/L)
dB(A)
38/36/33
38/36/33
38/36/33
45/42/36
45/42/36
Heat Exchanger
Fenestrate plain film --hydrophilic film
Air Filter
PP
PP
PP
PP
PP
Insulation Material
Foamed
polystyrene
Foamed
polystyrene
Foamed
polystyrene
Foamed
polystyrene
Foamed
polystyrene
Refrigeration Control Device
EXV
EXV
EXV
EXV
EXV
Protection Device
Fuse
Fuse
Fuse
Fuse
Fuse
Panel Name
TC03
TC03
TC03
TC03
TC03
4.11 Super High Static Pressure Duct Type Indoor Unit
Model
GMV-ND07PHS/B
- T(U)
GMV-ND09PHS/
B- T(U)
GMV-ND12PHS/B
-T(U)
GMV-ND15PHS/B
-T(U)
Product code
CM810N0830
CM810N0790
CM810N0800
CM810N0770
Cooling Capacity
Btu/h
7500
9500
12000
15000
kW
2.2
2.8
3.5
4.4
Heating Capacity
Btu/h
8500
10500
13500
17000
kW
2.5
3.1
4
5
Casing Finish
Galvanized Steel plate
Dimensions
(W×D×H)
Outline
mm
700x700×300
700x700×300
1000×700×300
1000×700×300
inch
27-9/16×27-9/16
×11-13/16
27-9/16×27-9/16
×11-13/16
39-3/8×27-9/16
×11-13/16
39-3/8×27-9/16
×11-13/16
Packaging
mm
897×808×360
897×808×360
1205×813×360
1205×813×360
inch
35-5/16×32
×14-3/16
35-5/16×32
×14-3/16
47-7/16×32
×14-3/16
47-7/16×32
×14-3/16
Net Weight
lbs.
73
73
94
94
kg
33
33
42.6
42.6
Gross Weight
lbs.
86
86
108
108
kg
39
39
49
49
Pipe
Connections
Liquid Side
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
inch
Φ1/4
Φ1/4
Φ1/4
Φ1/4
Gas Side
mm
Φ9.52
Φ9.52
Φ12.7
Φ12.7
inch
Φ3/8
Φ3/8
Φ1/2
Φ1/2
Drain Pipe
mm
Φ25
Φ25
Φ25
Φ25
inch
Φ1
Φ1
Φ1
Φ1
Power Supply
1-phase 208/230V 60Hz
Fan
Type × Quantity
Centrifugal×1
Centrifugal×1
Centrifugal×2
Centrifugal×2
Driving Mechanism
Direct-driven
Direct-driven
Direct-driven
Direct-driven
Motor Type
BLDC
BLDC
BLDC
BLDC
Motor Power Input
W
/
/
/
/
Motor Running
Current
A
0.3
0.3
0.3
0.3
Airflow Rate
(H/M/L)
CFM
324/282/235
324/282/235
353/294/247
500/412/353
m
3
/h
550/480/400
550/480/400
600/500/420
850/700/600
External
Static
Pressure
Default
inchW.G
0.24
0.24
0.24
0.24
Pa
60
60
60
60
Range
inchW.G
0~0.6
0~0.6
0~0.6
0~0.6
Pa
0~150
0~150
0~150
0~150
