4.12 Air Handler Type Indoor Unit
Model
GMV-ND09A/
A-T(U)
GMV-ND12A/
A-T(U)
GMV-ND18A/
A-T(U)
GMV-ND24A/
A-T(U)
GMV-ND30A/
A-T(U)
Product Code
CM810N1900
CM810N1910
CM810N1890
CM810N0660
CM810N0670
Cooling Capacity
Btu/h
9500
12000
18000
24000
30000
kW
2.8
3.5
5.3
7.0
8.8
Heating Capacity
Btu/h
10500
13500
20000
27000
34000
kW
3.1
4.0
5.9
7.9
10.0
Casing Finish
Galvanized Steel plate
Dimensions
(W×D×H)
Outline
mm
460x540×1105
460x540×1105
460x540×1105
460x540×1105
460x540×1105
inch
18-1/8×21-1/4
×43-1/2
18-1/8×21-1/4
×43-1/2
18-1/8×21-1/4
×43-1/2
18-1/8×21-1/4
×43-1/2
18-1/8×21-1/4
×43-1/2
Packaging
mm
517×620×1170
517×620×1170
517×620×1170
517×620×1170
517×620×1170
inch
20-3/8×24-3/8
×46-1/8
20-3/8×24-3/8
×46-1/8
20-3/8×24-3/8
×46-1/8
20-3/8×24-3/8
×46-1/8
20-3/8×24-3/8
×46-1/8
Net Weight
lbs.
119
119
124
124
124
kg
54
54
56
56
56
Gross Weight
lbs.
128
128
135
135
135
kg
58
58
61
61
61
Pipe
Connections
Liquid Side
mm
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Φ9.52
inch
Φ1/4
Φ1/4
Φ3/8
Φ3/8
Φ3/8
Gas Side
mm
Φ9.52
Φ12.7
Φ15.9
Φ15.9
Φ15.9
inch
Φ3/8
Φ1/2
Φ5/8
Φ5/8
Φ5/8
Drain Pipe
/
G1
G1
G1
G1
G1
Power Supply
1-phase 208/230V 60Hz
Fan
Type × Quantity
Centrifugal×1
Centrifugal×1
Centrifugal×1
Centrifugal×1
Centrifugal×1
Driving Mechanism
Direct-driven
Direct-driven
Direct-driven
Direct-driven
Direct-driven
Motor Type
BLDC
BLDC
BLDC
BLDC
BLDC
Motor Power Input
W
55.0
55.0
122.5
122.5
183.7
Motor Running
Current
A
1.1
1.1
1.1
1.1
1.4
Airflow
Rate(H/M/L)
CFM
559/383/324
559/383/324
824/706/559
824/706/559
882/706/559
m
3
/h
950/650/550
950/650/550
1400/1200/950
1400/1200/950
1500/1200/950
External
Static
Pressure
Default
inchW.G
0.1
0.1
0.1
0.1
0.15
Pa
25
25
25
25
37
Range
inchW.G
0~0.3
0~0.3
0~0.3
0~0.3
0~0.3
Pa
0~75
0~75
0~75
0~75
0~75
Sound Pressure Level(H/M/L)
dB(A)
36/34/32
36/34/32
45/43/41
45/43/41
46/44/42
Heat Exchanger
Fenestrate plain film -- hydrophilic film
Air Filter
PP
PP
PP
PP
PP
Insulation Material
Foamed polystyrene
Refrigeration Control Device
EXV
EXV
EXV
EXV
EXV
Protection Device
Fuse
Fuse
Fuse
Fuse
Fuse
