5.14 1-way Cassette Type Indoor Unit
Exploded View of GMV-ND07TD/A-T(U) / GMV-ND09TD/A-T(U) / GMV-ND12TD/A-T(U)
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND07TD/A-T(U)
CM502N0151
GMV-ND09TD/A-T(U)
CM502N0161
Part code
Quantity
Part code
Quantity
1
Remote Controller
30510589
1
30510589
1
2
Drain Hose Sub-Assy
05232050
1
05232050
1
3
Temperature Sensor
39008000079G
1
39008000079G
1
4
Water Level Switch
4501270301
1
4501270301
1
5
Water Pump Assy
15404100005
1
15404100005
1
6
Pump Drainpipe
26905288
1
26905288
1
7
Water Pump
4313822001
1
4313822001
1
8
Hook
02112466
4
02112466
4
9
Right Side Plate Sub-Assy
01314100023
1
01314100023
1
