HEIDENHAIN TNC 426, TNC 430 81
4.12 Pallet Management
With the arrow keys and ENT, select the position that you wish to
confirm. Then press the ALL VALUES soft key so that the TNC saves
the respective coordinates of all active axes in the pallet table. With
the PRESENT VALUE soft key, the TNC saves the coordinates of the
axis on which the highlight in the pallet table is presently located.
If you have not defined a pallet before an NC program, the
programmed coordinates are then referenced to the
machine datum. If you do not define an entry, the datum
that was set manually remains active.
Editing function Soft key
Select beginning of table
Select end of table
Select previous page in table
Select next page in table
Insert the last line in the table
Delete the last line in the table
Go to the beginning of the next line
Add the entered number of lines to the end of the
table
Copy the highlighted field (2nd soft-key row)
Insert the copied field (2nd soft-key row)
