HEIDENHAIN TNC 426, TNC 430 41
4.3 Standard File Management
4.3 Standard File Management
Note
Calling the file manager
Press the PGM MGT key: The TNC displays the file
management window (see figure at right)
The window shows you all of the files that are stored in the TNC. Each
file is shown with additional information:
The standard file management is best if you wish to save
all files in one directory, or if you are well practiced in the
file management of old TNC controls.
To use the standard file management, set the MOD
function PGM MGT (see “Configuring PGM MGT” on page
433) to Standard.
Display Meaning
FILE NAME Name with up to 16 characters and file type
BYTE File size in bytes
STATUS
E
S
M
P
Properties of the file:
Program is selected in the Programming and
Editing mode of operation.
Program is selected in the Test Run mode of
operation.
Program is selected in a program run
operating mode.
File is protected against editing and erasure.
