18 2 Manual Operation and Setup
2.2 Moving the Machine Axes
2.2 Moving the Machine Axes
Note
To traverse with the machine axis direction
buttons:
Select the Manual Operation mode.
Press the machine axis-direction button and hold it as
long as you wish the axis to move, or
Move the axis continuously: Press and hold the
machine axis direction button, then press the
machine START button
To stop the axis, press the machine STOP button.
You can move several axes at a time with these two methods. You can
change the feed rate at which the axes are traversed with the F soft
key, see “Spindle Speed S, Feed Rate F and Miscellaneous Functions
M,” page 21.
Traversing with the machine axis direction buttons is a
machine-dependent function. The machine tool manual
provides further information.
and
